Introduction
Built on a high-performance Store-and-Forward architecture, this series offers significant port density with models providing up to 12 copper and 4 SFP ports in a single unit. This high port count makes it an excellent choice for larger-scale deployments in factory floors, transportation systems, and utility substations where numerous sensors, controllers, and cameras must be reliably connected to the network.
Mirroring the portfolio's commitment to durability, the IESMG 3012-4S A series is engineered for harsh environments. Its fan-less, energy-saving design is housed in a rugged IP40 enclosure, and it supports an extensive operating temperature range. Combined with dual redundant power inputs, these features make it a highly reliable core or aggregation switch capable of providing stable, long-term performance in demanding industrial settings.
IEEE 802.1p, IEEE 802.1s, IEEE 802.1D, IEEE 802.1W
MAC Address Table: 8K
Data Buffer: 4M
Maximum Frame Size: 9.6K Jumbo Frame
Flash Memory - 32M
Fiber: 4 or 12 x 100/1000Base-X SFP Slots
Console: 1 x RS232 (RJ45)
Power Consumption: IESMG 3012-4S: 12W, Protection: Overload Current Protection
Reverse Polarity Protection : 6KV Lightning Protection (Power Port)
6KV EFT Protection (Power Port)
4KV Surge Protection (Ethernet & Fiber Ports)
2.25KV DC Hi-pot Isolation (Ethernet Ports & Power)
8/15KV ESD Protection
Mounting: DIN Rail (standard), Wall mounting (with optional kit)
Dimensions: 169 x 117 x 66 mm
Weight: 1100g
Relative Humidity: 5 - 95% (non-condensing)
| Categories | AC Supply | DC Supply | Download |
|---|---|---|---|
| IESMG 3012-4S A | – |
