Introduction
IPSGR 1024-4S U S Hi, an unmanaged Power over Ethernet (PoE) switch. It is positioned within the industrial networking market as a high-density connectivity solution designed to meet the specific demands of system integrators and network engineers deploying infrastructure in challenging operational settings. Its core purpose is to deliver reliable, high-throughput data and power distribution in a robust, rack-mountable form factor.
The IPSGR 1024-4S U S Hi is engineered with a primary focus on industrial applications where environmental conditions are a critical factor. Its suitability for harsh environments is underscored by a wide operating temperature range, ensuring dependable performance where standard commercial-grade hardware would fail.
The switch provides abundant and flexible connectivity through its 24 Gigabit RJ45 ports and 4 Gigabit SFP combo ports, accommodating a mix of copper and fiber optic connections. This flexibility is complemented by a substantial PoE power budget, making it an ideal central hub for powering devices like IP cameras, wireless access points, and other network-enabled industrial equipmen
PoE: IEEE802.3af, IEEE802.3at
Fiber: 1000Base-SX/LX/LHX/XD/ZX/EZX
Throughput: Min 35Mpps
Switching Capacity: 48G
L2 MAC Address Table: 8K
SFP Ports: 4 x Gigabit SFP (Combo)
Power Connector: 3-pin removable screw terminal
Relay Connector: 2-pin removable screw terminal
Console Port: RS-232 (RJ45)
SFP: Link/Activity
PoE: On/Off
SFP (Fiber): Up to 110 km
Power Consumption: 20 W @ 110VAC (no PoE load)
Total PoE Budget: 390W
Fault Output: Relay Outputs
Protection: Surge (Power: 3KA, RJ45: 6KV)
Reverse Polarity: Present
Overload Current: Present
Storage Temperature: -20 to 70°C
Operating/Storage Humidity: 10 to 95% (non-condensing)
| Categories | AC Supply | DC Supply | Download |
|---|---|---|---|
| IPSGR 1024-4S U S Hi | – |
